| General Application List for Models Normally in Stock |
7' X 84 X 38/42 SK
Length: 7'
Width: 84"
Frame Width: Specify 38" or 42"
(For 42" Cab to Axle)
|
Application:1/2 and 3/4 ton pickup, factory equipped with single rear wheels and short box. |
8 1/2' X 84 X 38/42 SK
Length: 8 1/2'
Width: 84 "
Frame Width: Specify 38" or 42"
(For 56" Cab to Axle)
|
Application: 1/2, 3/4 and 1 ton pickup, factory equipped with single rear wheels and 8' pickup box. |
8 1/2' X 97 X 38/42 SK
Length: 8 1/2'
Width: 97"
Frame Width: Specify 38" or 42"
(For 56" Cab to Axle)
|
Application: 1 ton pickup factory equipped with rear dual wheels and 8' dually pickup box. |
9' 4" X 94 X 34 SK
Length: 9'4"
Width: 94"
Frame Width: 34"
(For 60" Cab to Axle)
|
Application: 1 ton cab and chassis truck with rear dual wheels and 60" cab to axle measurement. |
To ensure choosing the proper size bed for your truck, the following information should be known:
1. Cab to axle measurement (measure from back of cab to center of rear axle)
2. Rear tires measurement (measure outside to outside width of rear tires)
3. Frame rails (measure outside to outside of frame rails at rear of truck)
4. Year, make and model of truck
Note: Due to various chassis lengths and configurations, specific measurements may determine the fender well placement on skirted beds (i.e. 2003 Dodge is 58" cab to axle measurement, whereas Ford and Chevy are 56" on bed off models).
Bed Size & Prices
Prices Current as of May, 2013
• Model: 7' X 84 X 38/42 SK w/front boxes: $2,969
• Model: 8 1/2' X 84 X 38/42 SK w/front boxes: $3,016
• Model: 8 1/2' X 97 X 38/42 SK w/front boxes: $3,046
• Model: 9' 4" X 94 X 34 SK w/front boxes: $3,288
• For lower cost w/o skirted sides, click to view SS flatbeds.
Note: All truck flatbeds are sold as components only. It is the responsibility of the final installer or manufacturer to meet all state, federal D.O.T. and O.S.H.A. regulations.
Custom built trailers and other options are available. Call us with your needs.
Note: The price you see is the cash price!
F.O.B. Colfax, WI
(If payment option is credit card, please call ahead for details.)
No additional freight or other hidden charges!
(5.5% Wisconsin sales tax applies to all purchases)
|
We at Johnson Trailer Co. are constantly striving to bring you the latest and most innovative designs at competitive prices. We are commited to updating and improving the performance of our products. Johnson Trailer Co. intends that the information, specifications, and prices available on this website be as accurate and up-to-date as possible. We cannot guarantee complete accuracy of information on this website.
|
|
